ZLYJ Series Yakakwira Torque Imwe Sikirivha Extruder Gearbox

Tsanangudzo Pfupi

ZLYJ yakatevedzana yakakwira torque gearbox imhando yeyakakosha giya unit yakatsvagirwa uye yakagadziridzwa nekuunza kunze tekinoroji yepamusoro yemazino akaomarara pasi. Iyo gearbox ine yakakwira axial thrust, inobuda torque uye simba, uye inoshandiswa zvakanyanya mumunda werabha uye.plastiki extrusion.

Product Detail

Product Tags

Basic Information

Input Power 10KW~633KW
Screw Diameter 45-150mm
Output Torque 1528N · m ~ 42338N · m
Input Speed 600-1500RPM
Output Speed Kubva pane Ratio
Gear Material 20CrNi2MoA High-Simba Alloy Steel
Housing Material Cast Iron
Gear Processing CNC Kukuya
Brand of Bearings ZWZ, NSK,FAG nezvimwe.
Brand yeOiri Chisimbiso FAG,NAK, etc.
Pamusoro Kuoma Kwemagiya HRC54~62
Gear Accuracy Grade 6
Kupisa Kurapa Carburizing, Kudzima
Cooling Mode Coil Kutonhodza, Tubular Inotonhorera
Output Mode Hollow Shaft Output
Input Mode Solid Shaft


Product Description

ZLYJ yakatevedzana yakakwira torque gearbox imhando yeyakakosha giya unit yakatsvagirwa uye yakagadziridzwa nekuunza kunze tekinoroji yepamusoro yemazino akaomarara pasi. Iyo gearbox ine yakakwira axial thrust, inobuda torque uye simba, uye inoshandiswa zvakanyanya mumunda werabha uye epurasitiki extrusion.

Product Feature
1.Compact design.
2 Kuomarara kwepamusoro, kuomarara kwepamusoro uye kusimba kwakanyanya.
3.Low noise.
4.High axial kutakura simba.
5. Kuvimbika kwekushanda kwepamusoro.
6.Perfect mafuta leakage kudzivirira kuita.
7.Excellent heat dissipation performance.
8.Forced lubrication system nekuwedzera kwebhokisi nzvimbo

Technical Parameter

Spec.(ZLYJ) Ratio Range Motokari Simba (KW) Sipidhi yekupinda (RPM) Output Torque (N·M) Screw Diameter (mm)
133 6.3/8/10/12.5/14/16/18/20 10~30 ≦1500 1528~2174 Ø45/50
146 6.3/8/10/12.5/14/16/18/20 12~54 ≦1500 3183~3438 Ø55
160 6.3/8/10/12.5/14/16/18/20 14~59 ≦1500 3700~3838 Ø65
180 6.3/8/10/12.5/14/16/18/20 23~97 ≦1500 5600~6600 Ø65
200 6.3/8/10/12.5/14/16/18/20 33~110 ≦1500 7100~8400 Ø75
225 6.3/8/10/12.5/14/16/18/20 43~170 ≦1500 10792~11352 Ø90
250 6.3/8/10/12.5/14/16/18/20 54~208 ≦1500 12961~13752 Ø100
280 6.3/8/10/12.5/14/16/18/20 88~330 ≦1500 21010~22738 Ø105/Ø110
320 6.3/8/10/12.5/14/16/18/20 128~455 ≦1500 28968-32597 Ø120
360 6.3/8/10/12.5/14/16/18/20 156~633 ≦1500 35559~42338 Ø130/150

Application
ZLYJ yakatevedzana yakakwira torque gearbox inoshandiswa zvakanyanya mumatayi erabha, waya netambo, kuumba gomba, mapaipi, waya,rabha yemabhandi ekutakurisa, epurasitiki mafirimu/mashizha e.g. kurongedza mafirimu, mabhegi e tote, tarps dzekunze, zvekurongedza zvinhu, thermal insulation board (polystyrene).

FAQ

Mubvunzo: Ungasarudza sei a gearbox uyegear speed reducer?

A: Unogona kutarisa kukhathalogi yedu kuti usarudze chimiro chechigadzirwa kana isu tinogonawo kukurudzira modhi uye maratidziro mushure mekupa iyo inodiwa mota simba, yekubuda nekumhanya uye kumhanya chiyero, nezvimwe.

Mubvunzo: Tinogona sei kuvimbisachigadzirwakunaka?
A: Isu tine yakasimba yekugadzira dhizaini yekudzora maitiro uye kuyedza chikamu chimwe nechimwe chisati chaburitswa.Yedu giya bhokisi rekudzikisira ichaitawo inoenderana oparesheni bvunzo mushure mekuiswa, uye nekupa mushumo webvunzo. Kurongedza kwedu kuri mumakesi emapuranga akanyanya kutumirwa kunze kwenyika kuti tive nechokwadi chekufambisa.
Q: Sei ndichisarudza kambani yako?
A: a) Isu tiri vamwe vevanotungamira vagadziri uye vanotengesa kunze kwemidziyo yekufambisa giya.
b) Kambani yedu yakagadzira zvigadzirwa zvegiya kweanoda kusvika makore makumi maviri neruzivo rwakapfumauye tekinoroji yepamusoro.
c) Tinogona kupa yakanakisa mhando uye yakanakisa sevhisi nemitengo inokwikwidza yezvigadzirwa.

Q: Chiiwako MOQ uyemazwi ekubhadhara?

A:MOQ chinhu chimwe chete.T/T neL/C zvinogamuchirwa,uye mamwe mazwi anogonawo kutaurirana.

Mubvunzo: Unogona here kupa magwaro akakodzera zvezvinhu?

A:Ehe, tinogona kupa akawanda zvinyorwa zvinosanganisira bhuku revashandisi, repoti yekuyedza, yemhando yekuongorora, inishuwarenzi yekutumira, chitupa chekwakabva, rondedzero yekutakura, invoice yekutengesa, bhiri rekutakura, nezvimwe.
